A differential brace aids the OEM differential bushings by keeping the differential from moving under heavy load whether that be during launches or track driving.
Most braces on the market block access to the differential drain plug and sensor, which proves to be quite a pain for those who drive their car hard as the differential fluid should be changed somewhat regularly based on usage.
Additionally, most braces on the market require drilling into the subframe (as all braces interface between the differential case and the subframe) despite there being 2 holes already being present.
The Rapid Designs A90 Supra Differential Brace solves these pain points:
Effectively limits differential movement, reducing wheel hop and potential drivetrain damage
Cost effective while not skimping on material quality
Allows access to the differential drain plug AND sensor
Utilizes the holes already present in the subframe such that the installation can be reversed at any time
Blocks a minimal amount of cooling fin surface area to allow the differential to maintain optimal cooling.
Minimal if any increase to NVH
Two versions are available with 5 different colors!
4 - Bolt Standard Version:
Original design meant to preserve OEM differential bushings by connecting the differential to the subframe via a rigid mounting strategy.
3 - Bolt Diff Cooler Version:
Similar to the 4 - Bolt Standard version with the removal of the bottom right mounting hole. This version is for those with differential coolers as it should interfere less with hose routing and doesnt require the removal of the hoses to mount the brace.
What's included?
1x - Differential Brace
1x - Subframe insert
2x - M8 × 25mm bolts
3x to x4 (ver specific) - M10 × 85mm bolts
2x - M8 wedgelock washers
3x to 4x (ver specific) - M10 wedgelock washers
NOTE: As explained below, you are placing an order as a group-buy, thus shipping times will be longer due to the nature of ordering from my manufacturer, packaging, and fulfillment.
Version:
Color:
Get notified by email when this product is in stock.
A differential brace aids the OEM differential bushings by keeping the differential from moving under heavy load whether that be during launches or track driving.
Most braces on the market block access to the differential drain plug and sensor, which proves to be quite a pain for those who drive their car hard as the differential fluid should be changed somewhat regularly based on usage.
Additionally, most braces on the market require drilling into the subframe (as all braces interface between the differential case and the subframe) despite there being 2 holes already being present.
The Rapid Designs A90 Supra Differential Brace solves these pain points:
Effectively limits differential movement, reducing wheel hop and potential drivetrain damage
Cost effective while not skimping on material quality
Allows access to the differential drain plug AND sensor
Utilizes the holes already present in the subframe such that the installation can be reversed at any time
Blocks a minimal amount of cooling fin surface area to allow the differential to maintain optimal cooling.
Minimal if any increase to NVH
Two versions are available with 5 different colors!
4 - Bolt Standard Version:
Original design meant to preserve OEM differential bushings by connecting the differential to the subframe via a rigid mounting strategy.
3 - Bolt Diff Cooler Version:
Similar to the 4 - Bolt Standard version with the removal of the bottom right mounting hole. This version is for those with differential coolers as it should interfere less with hose routing and doesnt require the removal of the hoses to mount the brace.
What's included?
1x - Differential Brace
1x - Subframe insert
2x - M8 × 25mm bolts
3x to x4 (ver specific) - M10 × 85mm bolts
2x - M8 wedgelock washers
3x to 4x (ver specific) - M10 wedgelock washers
NOTE: As explained below, you are placing an order as a group-buy, thus shipping times will be longer due to the nature of ordering from my manufacturer, packaging, and fulfillment.
NOTE: expect a longer wait time for shipment. As a “group-buy”, I will be placing an order for the specified number of variants collected during the “group-buy” period. Expected turnaround time for production is ~15 days, afterword there is shipping to me for packaging and order fulfillment to be done by myself. Your patience is greatly appreciated! :)
